KR CYBERTECH nano ARC


The KR CYBERTECH nano ARC product family is optimized for continuous-path applications such as arc welding and the application of adhesives and sealants. The industrial robots offer ideal performance combined with a high power density – for maximum economy at low cost.

Cost-effective, flexible robot for applications such as gas shielded welding, bonding and coating or laser cutting



Load capacity [kg]： 6 - 8 Reach [mm] (arm length) 1421 - 2010

Technical Data

Technical Data



KR 6 R1440-2 arc HW EKR 6 R1840-2 arc HWKR 6 R2010-2 arc HW EKR 8 R1420 arc HWKR 8 R1440-2 arc HWKR 8 R1620 arc HW
Payload6 kg6 kg6 kg8 kg8 kg8 kg
Maximum reach1441 mm1843 mm2010 mm1421 mm1441 mm1621 mm
Construction typeHollow WristHollow WristHollow WristHollow WristHollow WristHollow Wrist
Version environmentStandardStandardStandardStandardStandardStandard
Mounting positionsCeiling, FloorAngle, Ceiling, Floor, WallCeiling, FloorAngle, Ceiling, Floor, WallAngle, Ceiling, Floor, WallAngle, Ceiling, Floor, Wall
Protection class






Applications

Applications

Integration Case

Integration Case

  • KUKA welding robot arm in the automotive industry metal welding industry applications
  • KUKA robotic arms help bring new opportunities for precision welding in the electronics industry
  • KUKA welding robotic arm helps metal tooling industry improve energy efficiency
